Description

MMC Flasher Advantages

MMC Flasher is an absolutely unique tool which allows to work with a great number of ECUs both via CAN bus and K-Line. MMC Flasher is unrivalled among other chip-tuning tools. Even though its coverage partly overlaps that of some free software, like EcuFlash (for MH8206F/MH8305F CPUs) it has some significant advantages which justify its price:

• There is no need to create XML files description files. Reading and writing are done with two button. What can be easier!
• You will never get the CPU type mixed up when using MMC Flasher. Reading and writing algorithms can be the same for some CPUs, but the file size is different. If you choose the wrong CPU type in EcuFlash, after reading and modifying it, and writing it again you can get a bricked ECU which could be difficult to recover.
• After reading MMC Flasher automatically compares the contents of the ECU flash memory with the contents of the buffer, and in case of any difference it gives you a warning. You are guaranteed to read what is in the ECU.
• MMC Flasher speed is considerably higher due to its unique algorithm.
• If you have a stock file you can recover an ECU from any state. It makes the work with ECUs absolutely safe.

MMC Flasher Key Features:

• A wide coverage of Japanese and Korean vehicles;
• Checksum calculation, transfer of IMMO synchronization code or ECU VID for a number of the supported ECUs;
• Regular updates and good technical support;
• New ECUs and CPU types are added constantly; It works via a J2534 device (CAN), Openport 2 can be used to the full extent (with built-in reflash connector).

Technical support is provided by the developer.

1 Module, h8/53x, SH7052, SH7055
Identification, full flash reading/writing;
MH7201F (128KB) – 1997 Space Wagon 2.4 GDI;
Galant 4G93 GDI; Mirage Dingo 1.5 4G15 GDI;
MH7202F (128KB) – the same Mitsubishi models as 7203; Mazda 626, 1998;
MH7203FA (128KB) – Mitsubishi Carisma, Pajero, Eclips, Galant 2000-2004;
Montero Pajero 3.2 DID 4m41 2002;
Hyundai Sonata 2.0 (Korea, Tagaz) 2004, Santa Fe 2.4 2001-2004, Tiburon 2.0 (Cupe), Matrix 1.8; Kia Sorrento 2.4, Magentis 2.0 2000-2004;
MH8206F (256KB) – Lancer IX MT;
MH8305F (512KB) – Lancer IX AT.

2 Module, Mitsubishi M32r
Map area reading/writing, full flash reading/writing, error reading/deleting, checksum correction;
MH8102F (512KB);
MH8201F (512KB);
MH8202F (512KB);
MH8301F (512KB) – from 2001 Montero Sport 3.5L; from 2001 Pajero 3.0;
MH8302F (512KB) – from 2004 Galant 2.4L MIVEC; Outlander 2003-2005; Outlander CU5W 2.4 AT MIVEC 07/05 – 12/08; from 2003 Montero Sport 3.5L 4WD; since 2004 Galant 3.8L V6; 06-09 Eclipse GT;
MH8303F (768KB) – from 2006 Outlander AWD AT; from 2006 Outlander 2.4L 4WD AT MIVEC;
MH8304F (512KB & 768KB) – from 2005 Galant 2.4L; Colt 1.3 2004-2008.

3 Module, Mitsubishi Lancer X1.5, Outlander JDM
Identification, map area reading/writing, full flash reading/writing, error reading/deleting, checksum correction, configuration data reading/writing;
MH8104F (512KB) CAN;
MH8104F (512KB) K-Line (repair/recovery);
MH8106F (1024KB) CAN;
MH8106F (1024KB) K-Line (repair/recovery);
EVO X ACD m32r (512KB) K-Line.

4 Module, Mazda Dorestyle
Map area reading/writing, full flash reading/writing, error reading/deleting, checksum correction;
Denso/Mitsubishi SH7058/SH705*

5 Module, Yamaha snowmobiles and Boats
Full flash reading/writing, checksum correction;

Yamaha F40/50/60 MH8102F(loaded ECU);
Yamaha RFX nitro MH8104F(not loaded ECU);
MH8106F;

6 Module, Mitsubishi Diesel Denso SH7058/7058S/7059
Identification, map area reading/writing, error reading/deleting, checksum correction;
Denso Mitsubishi 7058/7058S/7059

7 Module, Mazda M32r
Identification, map area reading/writing, full flash reading/writing, error reading/deleting, checksum correction;
Mazda M32r CPU 1.8/2.0/2.5 litres 2008+;
possible recovery from any state.

8 Module, Ford SIM28 and SIM29
Identification, map area reading/writing, error reading/deleting, checksum correction;
FOCUS 2, C-MAX, KUGA, FIESTA, FUSION etc., 1.4L-1.6L, from about 2004 to 2009.

9 Module, Ford Visteon ESU – 131, 411, 418, Benzin
Map area reading/writing, error reading/deleting, checksum correction;
FOCUS 2, C-MAX, etc., 1.8L, 2.0L, 2.3L from about 2004 to 2011.

10 Module, Kia / Hyundai SIM2K 140/141/241/341
Identification, map area writing, full flash reading, error reading/deleting, checksum correction.

11 Module, Ford Visteon ESU-312, 412, 415 Benzin
Identification, map area reading/writing, error reading/deleting;
MONDEO IV, S-MAX, GALAXY, etc., 1.8L-2.0L, from about 2004 to 2011.

13 Module, Mazda Diesel Denso SH7058 (none BGA)
Identification, map area reading/writing, error reading/deleting;
RF7x, RF8x ECUs, SH7058

14 Module, Ford Diesel Delphi DCM3.5
Identification, map area reading/writing, error reading/deleting, configuration data reading/writing, virtual reading;
FOCUS (III SERIES) 2.0 16V TdCi (115 HP);
C-MAX (II) 2.0 16V TdCi (115 HP);
GALAXY (III) 2.0 16V TdCi (140/163 HP);
KUGA 2.0 16V TdCi (140/163 HP);
MONDEO (IV SERIES) 1.8 16V TdCi (125 HP);
MONDEO (IV SERIES) 2.0 16V TdCi (115/140/163 HP);
S-MAX 2.0 16V TdCi (115/138/163 HP).

15 Module, Ford Bosch ME 9.0 Petrol (Turbo)
Identification, map area writing, error reading/deleting.

18 Module, MH8110 Mazda CX7, 3, 6 2010+
Identification, map area reading/writing, error reading/deleting, checksum correction;
Mazda CX7 2.5 AT 2011 L587EB000L5XA050 L587 18 881B 163hp;
Mazda CX7 2.3T AT 2010 L3CKEG000L3TB051 L3CK 18 881G 238hp;
Mazda 3 2.5 AT 2011 L5E8EB000L5XA020 L5E8 18 881B USA;
Mazda 3 2.0 MT 20xx LFAREB000LFX6050 LFAR 18 881B;
Mazda 3 2.0 AT 2011 LFJPEA000LFXA060 LFJP 18 881A;
Mazda 5 2.0 AT 2012 LFFREE000LFXA060 LFFR 18 881E.

19 Module, Ford SIM210, SIM22
Map area reading/writing, error reading/deleting, checksum correction;
FOCUS 2, C-MAX, KUGA, FIESTA, FUSION, etc., 1.3L-1.6L, from about 2004 to 2009.

20 Module, Kia/Hundai EDC17
Identification, map area reading (slow)/writing via CAN bus, error reading/deleting, virtual reading, checksum correction;

EDC17C08 and EDC17CP14 with any TPROT are supported.

21 Module, Ford Diesel SID206
Identification, map area reading/writing, error reading/deleting, checksum correction;
KUGA, MONDEO 6(IV), FOCUS 2(II), GALAXY 2(II), S-MAX, ESCAPE, FIESTA 7(VII), FUSION, TRANSIT CONNECT 2005-2010.

22 Module, Ford, Siemens VDO EMS2102 and EMS2101
Map area reading/writing, error reading/deleting, checksum correction;
MONDEO, FIESTA, etc., 1.2L-1.6L.

23 Module, Mazda CX5 2.2 Diesel
Identification, map area reading/writing, error reading/deleting, checksum correction; configuration data reading/writing;
Mazda CX5 2.2D

24 Module, Mazda 1.3 1.5 1.6 AT/MT Denso 2009+
Identification, map area reading/writing, error reading/deleting, checksum correction; configuration data reading/writing, external EEPROM (VIN) reading/writing;
Mazda 1.3L, 1.5L, 1.6L with automatic and manual transmission.

25 Module, Mitsubishi MH8115F
Identification, map area reading/writing, full flash reading/writing, error reading/deleting, checksum correction.

27 Module, Ford Bosch MED17.2
Identification, map area reading/writing, error reading/deleting, checksum correction, virtual reading, VBF into BIN conversion.

28 Module, Ford EMS2204
Identification, map area writing, full flash reading, error reading/deleting, checksum correction, virtual reading
Digital signature bypass, VBF into BIN conversion.

29 Module, Subaru Hitachi/Unisia Jecs
Identification, map area writing, full flash reading, error reading/deleting, checksum correction;
Hitachi / Unisia Jecs SH7058 WA12212930WWW, WA12212940WWW, WA12212970WWW.

30 Module, Honda/Acura K-line
Identification, map area writing, virtual reading, error reading/deleting, checksum correction.

31 Module, Mazda SkyA 2.0 2.5 (Mitsubishi ECU)
Identification, map area reading/writing, error reading/deleting, checksum correction; configuration data reading/writing;
Mazda CX5 2.0 AT 2012 PE2JEF000PE0B061 PE2J 18 881F 150hp;
Mazda 3 2.0 AT 2013 PSZKE0000PE0B020 USA;
Mazda 3 2.0 AT 2013 PE2K 18 881N USA;
Mazda 3 2.0 AT 2013 PE08 18 881N USA;
PEBB-18881-D – Mazda CX-5 2.0l AT 4WD Mitsubishi;
PEBA-18881-D – Mazda CX-5 2.0l AT 2WD Mitsubishi.

32 Module, K-line
Identification, map area reading/writing, error reading/deleting;
MAGNETI MARELLI 7GV / 7GVE / 4HV;
Simos 7.1 / 7PP / 7.1A.

33 Module, Mazda SkyA 2.0 2.5 (Denso ECU)
Identification, map area reading/writing, error reading/deleting, checksum correction; configuration data reading/writing.

34 Module, Nissan Hitachi TCM
Identification, map area reading/writing, virtual reading, error reading/deleting.

35 Module, SID208 PSA (Peugeot/Citroen)
Identification, map area writing, full flash reading/writing, EEPROM reading/writing, error reading/deleting, checksum correction.

36 Module, Denso SH705x+EEPROM
Full flash reading/writing, EEPROM reading/writing, checksum correction;
Denso SH7055, SH7058, SH7059.

37 Module, Nissan/Infiniti Hitachi SH705x, SH7253x CAN
Identification, map area writing, full flash reading, error reading/deleting, checksum correction.

38 Module, Honda/Acura CAN
Identification, map area writing, full flash reading, error reading/deleting, checksum correction.
Matsushita SH7058 1024KB;
Matsushita SH72543 2048KB;
Continental MPC5554 2048KB;
Temic MPC5554 2048KB;
Keihin MPC5566 3072KB;
Keihin SH72543 2048KB;
Keihin SH7058 1024KB;
Hitachi SH7059 1536KB;
Hitachi SH72543 2048KB.

39 Module, Nissan/Infiniti Hitachi/Unisia Jecs SH705x, K-line
Identification, map area writing, full flash reading, error reading/deleting, checksum correction
SH705415N;
SH705507N;
SH705513N;
SH705520N;
SH705524N;
SH705529N;
SH705821N;
SH705823N.

40 Module, Suzuki Hitachi SH7058, K-line
Identification, map area reading/writing, error reading/deleting, checksum correction.

41 Module, BMW Bosch F-series E-NET
Identification, virtual reading, map area writing, error reading/deleting, configuration data reading/writing, checksum correction.
00000316 DDE721b-ME(D)/EDC17;
0000063C DDE73a-ME(D)/EDC17;
0000076B DDE731a-ME(D)/EDC17;
000007D0 MEVD17.2;
00000A0A DDE701a-ME(D)/EDC17;
00000ABD MEVD17.2.4;
00000C49 ME17.2;
00000C9D DDE741a-ME(D)/EDC17;
00000E2A MEVD17.2.5;
00000FEE MEVD17.2.6;
00001218 DDE701P-ME(D)/EDC17;
0000121F DDE721P-ME(D)/EDC17;
00001242 MEVD17.2.8;
00001243 MEVD17.2.4;
000013E5 MEVD17.2.9;
00001400 MEVD17.2.4;
00001501 DDE751-ME(D)/EDC17;
000017D3 MEVD17.2.6;
000018FF MEVD17.2.9;
00001901 MEVD17.2.9;
00001933 MEVD17.2.9;
000019A7 MEVD17.2.9;
000019DC MEVD17.2.G;
00001A83 MEVD17.2.G;
00001ABD MEVD17.2.6;
00001BD5 MEVD17.2.9;
00001C19 MEVD17.2.6;
00001CA3 MEVD17.2.9;
0000208A MEVD17.2.3;
0000208C MEVD17.2.3;
000020D5 MEVD17.2.G;
0000226E DDE741P-ME(D)/EDC17;
00002666 DDE742-ME(D)/EDC17;
00003064 ME17.2.4;
000030BB DME-MEVD17.2.G;
00003421 ME17.2.4;
00003747 ME17.2.4;
00003DE7 MEVD17.2.3

42 Module, Renault Gasoline
Identification, map area reading/writing, error reading/deleting, checksum correction.
Logan / Sandero EMS3120 TC1738 [2048KB] CAN;
Fluence / Megane EMS3120 TC1738 [2048KB] CAN;
Fluence / Megane EMS3110 TC1766 [1504KB] CAN;
Kangoo EMS3110 TC1766 [1504KB] CAN;
Sagem old S3000 SH7055 [512KB] CAN;
Sagem new S3000 SH7055 [512KB] CAN;
Valeo V40/V42 SH7058 [1024KB] CAN;
Duster / X-Ray EMS3125 TC1782 [2560KB] CAN.

43 Module, Nissan Hitachi GEN2 2014+ SH72533 CAN
Identification, map area reading/writing, error reading/deleting, checksum correction.

44 Module, Toyota Gen1 Test
Identification, map area writing, virtual reading, error reading/deleting, checksum correction.

45 Module, Subaru Denso
Identification, map area reading/writing, full flash reading, error reading/deleting, checksum correction.
BRZ SH72531 [1280KB] CAN 2013+;
SH7058 [1024KB] CAN 2007+;
SH7058 [1024KB] K-line 2003+;
SH7055 [512KB] K-line;
SH7055 JDM [512KB] K-line.

46 Module, Ford DCU 101/102/104/201
Map area reading/writing, error reading/deleting, checksum correction.

47 Module, Ford USA
Identification, map area reading/writing, error reading/deleting, checksum correction.
M799G; PCM170F; PCM150F; PCM190F; Meg9.8.1

48 Module, Mazda SkyA 1.5/1.6/2.0/2.5 (Denso Crypto)
Identification, map area reading/writing, error reading/deleting, checksum correction.
Mazda3 / CX5 / 6, 1.5, 2.0, 2.5L SKYACTIV-G Z6 1.6L

49 Module, Ford SID208/SID209
Identification, map area writing, full flash reading, virtual reading, error reading/deleting, checksum correction.
Unlocking in BSL required.

50 Module, Kia/Hyundai EDC16
Identification, map area writing, error reading/deleting, checksum correction.
EDC16C39-5.41 and EDC16CP34-5.30

51 Module, Ford EMS2214
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.

52 Module, Ford EMS2205
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.

53 Module, Ford EMS2211
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.

54 Module, Ford EMS2510/EMS2511
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.
VBF into BIN conversion

55 Module, Ford DCM6.1 Diesel
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.

56 Module, MED/EDC 17 UDS
Identification, map area writing, virtual reading, error reading/deleting, checksum correction.
ME(D)17.1/17.5/17.1.1/17.1.6/17.5.5/17.5.20/17.5.21/17.5.22/17.5.24/17.5.25/17.5.26/

EDC17C46/C54/C64/CP04/CP14/CP20/CP24/CP44

57 Module, TCM Powershift 6DCT250
Identification, map area reading/writing, virtual reading, error reading/deleting, checksum correction.

59 Module, Valeo V46 (Peugeot/Citroen)
Identification, map area reading/writing, error reading/deleting, checksum correction.

62 Module, Volkswagen AG TP2.0/KWP2000 FINAL TEST
Identification, virtual reading, map area writing, error reading/deleting, checksum correction.

63 Module, Mitsubishi ETACS & ECU Coding
Identification, configuration data reading/writing/editing, error reading/deleting, checksum correction.

Editing of the functions supported in the ECU or ETACS depending on the vehicle, MY, market and firmware. Possible IMMO OFF.

65 Module, Suzuki MH8115 MH8114
Identification, full flash reading/writing, checksum correction;

Bench work required

66 Module, Ford EMS24xx
Identification, map area reading/writing, error reading/deleting, checksum correction, virtual reading from Ford server, vbf conversion.

67 Module, BMW Bosch MED17/EDC17 E series
Identification, virtual reading, map area writing, checksum correction (digital signature bypass), error reading/deleting;

Tabs:

CAN – for the Master ECU;
Slave – for writing the second ECU (Slave);
Stock – for getting back to the stock without using the patch to keep the original CVN, for both Master and Slave ECUs;
Repair – for emergency situations, for both Master and Slave ECUs.

69 Module, Denso Gen2 SH72xx
Identification, full flash reading/writing, checksum correction, error reading/deleting, EEPROM reading/writing;

Bench work required

70 Module, Isuzu Transtron
Identification, full flash reading, map area writing, error reading/deleting, checksum correction.

Automatic file size defition. All markets and kinds of vehicles are supported. Reading full takes about 1 hour, writing 10-15 minutes for cars and trucks. Special vehicles writing – 1 hour based on SH7059 processor.

Supported processors: SH7055, SH7058, SH7059, SH72533, SH72544

Supported engines: 4HK1, 4JJ1, 6UZ1, 4JK1, 6HK1

VIN number editing; readig/erasing DTC.

For SH7055 only read via K-Line now is supported. NO WRITING.

All other MCUs SH7058/SH7059/SH72533/SH72544 – reading/writing via K-line and CAN bus.

71 Module, Mitsubishi TCM\CVT\AT\4WD\ACD
Identification, full flash reading, map area writing, checksum correction.

73 Module, Mercedes MED17\EDC17
Identification, map area reading/writing, full flash writing, virtual reading checksum correction, error reading/deleting.

MED17: virtual reading only. Map area writing for tuned files. Stock files can be written in boot and code from the virtual reading database.

EDC17: vitual and real reading of map area. Map area writing for tuned files. Stock files can be written in boot and code from the virtual reading database.

74 Module, Mazda TCM MH8104
Identification, full flash reading/writing, map area writing, error reading/deleting, checksum correction.

ECU cloning on the bench, without opening. TCUs in metal casing are supported, TCUs in plastic casing are not.

78 Module, Mazda Gen4 Denso & Mitsubishi SKYACTIV G
Identification, calibration area reading/writing, errors reading/writing, checksum correction.

79 Module, Yamaha & Kawasaki SH725xx
Identification, full flash reading/writing, checksum correction;

80 Module, Nissan/Renault UDS Hitachi/Bosch/Continental
Identification, calibration area reading/writing, errors reading/writing, checksum correction.

81 Module, Mitsubishi EDC17CP52/EDC7C4/EDC16C31

82 Module, Isuzu Denso
Identification, Fullflash reading/writing on the bench, map area writing via OBD, error reading/erasing, checksum calculation.

85 Module [ Master ], Isuzu Transtron NO READING
Identification, map area writing, error reading/deleting, checksum correction;

Supported processors: SH7058, SH7059, SH72533, SH72544

85 Module [ Slave ], Isuzu Transtron
Identification, map area writing, error reading/deleting, checksum correction;

86 Module, Isuzu UDS 4JJ3
Identification, virtual reading, calibration area writing, errors reading/writing, checksum correction.

Works in bench mode and via OBD2. ECU opening is not required.

86 Module Master Isuzu UDS 4JJ3 (TC265D)
Allows encrypting files for module 86

87 Module, Ford TCM PowerStroke
Identification, virtual reading, calibration area writing, errors reading/writing, checksum correction.

88 Module, Ford SID211 OBD2
Identification, full image data reading, calibration area writing, errors reading/writing, checksum correction.

89 Module, Ford Continental SID208 SID209 OBD
Identification, full image data reading, calibration area writing, errors reading/writing, checksum correction.

Attention! Not all the software versions are supported!

94 Module [ Master ], Kawasaki MH8610

96 Module [ Slave ], Kawasaki MH8610

98 Module, Nissan Hitachi SH72531 EV/HEV

100 Module, Nissan Hitachi TCM RE5

103 Module, Nissan Hitachi SH72533/SH72543

103 Module Master, Nissan Hitachi SH72533/SH72543
Gen1 and Gen2 ECU cloning, file encription for the slave dongle

103 Module Slave, Nissan Hitachi SH72533/SH72543
The module only works together with the master dongle

105 Module, Isuzu Delphi

106 Module, Denso Gen2 MPC5746R (1N83M) test
